Based on
STC12C5A60S2 single- chip computer, a multi- functional monitoring system for
household use is designed, which has the characteristics of low development
cost, synchronous display of multi-sensor data on online and offline terminals,
special voice flash alarm for fire characteristic parameters locally, and
synchronous color change alarm for online APP client interface. Firstly, fire
signals are monitored in real time by infrared flame, photoresistor,
temperature, humidity, poisonous gas and smoke sensor modules. Then, the
characteristic parameters of these signals are processed by A/D conversion and
algorithm analysis in sequence. Then, a micro-network is constructed by
Bluetooth wireless transmission and serial communication technology to realize
data remote distance transmission,and with the help of easy language, PC
Android APP development environment, LCD, start and stop function keys,
decoding chip, relay group and multi-channel voice playback board,build online
and offline monitoring and alarm terminal. The experimental results show that
the system has strong control lability and real-time, the rate of missed and
false alarm of home fire is further reduced, and the user's response ability to
alarm signal is also improved.
